HP / Keysight / Agilent N4220A

HP Agilent N4220A Packet Analysis Probe for PCI Express

HP / Keysight / Agilent N4220A - main view
$350.00

Condition: For parts or not working

Product Details

Model:
N4220A
Category:
Probes
Condition:
For parts or not working
Availability:
In Stock - Ready to Ship

Specifications

Model:
N4220A
Manufacturer:
HP Agilent
Brand:
Agilent / HP

Product Description


HP Agilent N4220A Packet Analysis Probe for PCI Express

*Untested



Description

 The N4220A packet analysis probe for PCI Express adds packet-based trigger and display for a PCI Express bus. With this probe you can capture and view data traveling across PCI Express at full frequency (2.5+GT/s) in high level format for viewing on the 16700 Series logic analysis system. The tool decodes the 8b/10b encoded and scrambled PCI Express data to present a packet-based listing.

The N4220A PCI Express analysis probe decodes a number of pre-defined PCI Express packets and also allows for user-defined packet setup. Describe your trigger at the packet level.

All PCI Express traffic is time-stamped in the logic analyzer for time-correlation measurements with other system buses such as a µProcessor system bus (FSB), memory interface, Serial ATA, etc.





Key Features & Specifications



  • Non-intrusive probing of PCI Express slots and chip-to-chip links (link widths: x16, x8, x4, x2, x1)
  • Supports PCI Express at full frequency - 2.5+GT/s
  • Triggering on and decode a PCI Express bus at the packet level
  • Please refer to the datasheet for more information

Sold as pictured, no additional software, manuals or accessories provided.













Ready to Buy?

Click the button below to purchase this item. We'll contact you to complete the transaction.

BUY NOW - $350.00
