| 015 |
6 GHz return-loss Measurement Accessory Kit |
| 071 |
Digital Demodulation H/W for S/N USUS4142/MY4140 Changed ot B7J on newer models |
| 0B0 |
Do not include manuals |
| 0B1 |
Add Manual Set |
| 0BV |
Service Documentation, Component Level |
| 0BW |
Service Documentation, Assembly Level |
| 107 |
Audio input 100 kOhm |
| 110 |
RF/uW internal preamplifier |
| 111 |
USB device side I/O interface |
| 115 |
512 MB user memory |
| 117 |
Secure memory erase |
| 119 |
Noise Figure Hardware Kit . Standard on all models S/N > US4222/MY4100. |
| 122 |
80 MHZ Bandwidth Digitizer |
| 123 |
Switchable MW preselector bypass |
| 124 |
Y-axis video output |
| 140 |
40 MHZ Bandwidth Digitizer |
| 1A7 |
PSA Series ISO 17025 compliant calibration with test data |
| 1CM |
Rackmount Kit |
| 1CN |
Handle kit |
| 1CP |
Rack mount kit with handles |
| 1CR |
Rack slide kit |
| 1DS |
RF internal preamplifier |
| 202 |
GSM w/EDGE Measurement Personality |
| 204 |
1xEV-DO Measurement Personality |
| 210 |
HSDPA/HSUPA measurement personality |
| 211 |
TD-SCDMA measurement personality |
| 212 |
TD-SCDMA Modulation Analysis Measurement Personality |
| 213 |
HSPA/8PSK for TD-SCDMA Modulation Analysis Measurement Personality |
| 214 |
1xEV-DV measurement personality |
| 215 |
External Source Control Measurement Personality |
| 217 |
WLAN Measurement Personality |
| 219 |
Noise figure measurement personality |
| 226 |
Phase noise measurement personality |
| 230 |
Benchlink web remote control software |
| 233 |
Built-in measuring receiver personality |
| 235 |
Wide BW digitizer external cal wizard |
| 239 |
EMC measurement personality |
| 23A |
AM/FM/PM triggering for measuring receiver |
| 23B |
CCITT filter for audio measurements |
| 241 |
Flexible digital modulation analysis |
| 266 |
Programming code compatibility suite measurement personality |
| 423 |
Switchable MicrowOptionave Preselector Bypass. Available for all models with S/N
|
| 426 |
Gated Sweep Hardware. Standard on all models >S/N US/MY4336. |
| 512 |
|
| 514 |
Rythm cable |
| 516 |
40 MHz BW IF output - low band |
| 517 |
Boris DIF --with opt 122 or 124 |
| 518 |
Natasha DIF -- no opt 122 or 124 |
| 520 |
Preselector bias cable - no opt HNQ |
| 627 |
Required for all options except HT1 |
| 628 |
Required for all options except 111 |
| 630 |
Required for option 110 without 123 |
| 631 |
Required for 123 without 110 |
| 632 |
Required for option 110 with 123 |
| 633 |
Required for all options except HS1, HS7 and HT1 |
| 903 |
PWR CORD USA 120V |
| A6J |
PSA Series ANSI Z540 compliant calibration with test data |
| AB1 |
Korea Quick Users Guide (Korean localization) |
| AB2 |
China Quick Users Guide (Chinese localization) |
| ABA |
U.S. Quick Users Guide (English localization) |
| ABD |
Germany Quick Users Guide (German localization) |
| ABE |
Spain Quick Users Guide (Spanish localization) |
| ABF |
France Quick Users Guide (French localization) |
| ABJ |
Japan Quick Users Guide (Japanese localization) |
| ABZ |
Italy Quick Users Guide (Italian localization) |
| ANE |
64 MB Flash Ram Memory. Shipped Standard on all 46A/47A/48A Models. Shipped Standard on all models >US/MY4222 |
| ATP02 |
ATP LEADTIME ITEM FOR E4443A-H20 |
| ATP04 |
ATP LEADTIME ITEM FOR E4443A-H7L |
| ATP05 |
ATP LEADTIME ITEM FOR E4443A-HB2 |
| ATP06 |
ATP LEADTIME ITEM FOR E4443A-HGT |
| ATP07 |
ATP LEADTIME ITEM FOR E4443A-HN9 |
| ATP08 |
ATP LEADTIME ITEM FOR E4443A-JMP |
| B78 |
CDMA2000 Measurement Personality |
| B7J |
Digital demodulation hardware |
| BAC |
CDMAOne Measurement Personality |
| BAE |
NADC,PDC Measurement Personality |
| BAF |
W-CDMA Measurement Personality |
| H20 |
20 MHz IF Output on rear panel. |
| H25 |
25 MHz IF Output |
| H26 |
High Band Preamplifier (Discontiued) Replaced by option 110. |
| H70 |
70 MHz IF Output |
| H7L |
Auxiliary Wideband Log Video Output |
| HB2 |
21.4 MHz IF Output |
| HB6 |
Prevention of unauthorized firmware upgrade |
| HBA |
Rear Panel RF Input |
| HGT |
Allows Gate width of less than 10 uSec. |
| HN8 |
Wideband Preselector Bypass (No Preselector) |
| HN9 |
80 MHz wide baseband IF output at 321.4 MHz for frequencies less than 3.05 GHz |
| HNQ |
I/Q Front Panel Output connectors with hardware for use with 89600A. |
| HS1 |
Increase level of security write protects to user files |
| HS7 |
Security erase software |
| HT1 |
GPS Interface Card for Trimble GPS |
| HY7 |
Improved Gain 70 MHz IF Output |
| JMP |
Rear panel jumper cable |
| N6171A |
MATLAB Software |
| N6171A-M01 |
MATLAB - Basic Package |
| N6171A-M02 |
MATLAB - Standard Package |
| N6171A-M03 |
MATLAB - Advanced Package |
| N9051A |
Pulse measurement software |
| N9051A-2FP |
Pulse measurement software, fixed, perpetual, license |
| N9051A-3FP |
Phase & Frequency Measurements |
| N9051A-4FP |
Extended Analysis & Statistics |
| PS-S20-01 |
Recommended Startup assistance |
| R-50C-001 |
Standard Calibration w/data. Replaced UK6 |
| R-50C-002 |
Traceable Calibration standards compliant initial receipt. (ANSI-Z540/17025) |
| R-50C-011-3 |
Agilent Calibration - 3 years |
| R-50C-011-5 |
Agilent Calibration - 5 years |
| R-50C-016-3 |
ISO 17025 Compliant Calibration - 3 years |
| R-50C-016-5 |
ISO 17025 Compliant Calibration - 5 years |
| R-50C-021-3 |
ANSI Z540-1-1994 Calibration - 3 years |
| R-50C-021-5 |
ANSI Z540-1-1994 Calibration - 5 years |
| R-51B-001-3C |
Return to Agilent Warranty - 3 years |
| R-51B-001-5C |
Return to Agilent Warranty - 5 years |
| R-51B-001-C |
Return to Agilent Warranty - 1 year |
| R-52A-001-3 |
3 Year Calibration License (Commercial) |
| R-52A-001-L |
Lifetime Calibration License (Commercial) |
| R-52A-002-3 |
3 Year Calibration License (Z540/17025) |
| R-52A-002-L |
Lifetime Calibration License (Z540/17025) |
| RMKT |
Agilent Refurbished Product (Do Not Use - Certiprime Option) |
| UE2 |
Firmware Kit. CD-ROM. |
| UK6 |
Commercial Cal Certificate with Data |
