Posital Fraba ACS-080-2-CA01-HE2-PM

Description

Milmega Power Amplifier

Key Features & Specifications

·        Application 2-Axes Position Monitoring and Leveling

·        Measurement Range   max. ± 80°, can be used for ± 60°

·        Absolute Accuracy       0.10°

·        Resolution 0.01°

Electrical Specifications

·        Supply Voltage   10 – 30 V DC (On power supplies comply with EN 50178)

·        Current Consumption   57 mA @ 10 V DC, 53 mA @ 24 V DC

·        EMC Emitted Interference    DIN EN 61000-6-4

·        EMC: Noise Immunity  DIN EN 61000-6-2

·        Reverse Polarity Protection  Yes

·        Short Circuit Protection         Yes
