| B10 |
External generator control for FSP, FSU, FSG, FSQ, ESU, ESCI, ESPI and for retrofit of |
| B100 |
I/Q memory extension 235 Msamples Extendable up to 705 Msamples (Not retrofittable, excludes FSP-B10) |
| B102 |
I/Q memory extension Extends FSQ-B100 to 705 Msamples (FSQ-B100 required) |
| B12 |
Output attenuator for tracking generator for FSU, FSQ |
| B17 |
Digital Baseband Interface Not retrofittable |
| B18 |
Removable Hard Disk (not retrofittable) |
| B19 |
Second Hard Disk for FSQ-B18 (for FSQ-B18, variant 1303.0400.03) |
| B21 |
LO/ZF connections for external mixers (for FSQ26, FSQ40,FSU26, FSU43, FSU46, FSU50) |
| B23 |
Preamplifier 20 dB to FSQ26, 3.6 GHz - 26.5 GHz (not retrofittable, requires FSU-B25) |
| B24 |
Preamplifier 30dB, 100 kHz to 50GHz (for FSMR26/43/50, FSQ26/40, FSU26/43/46/50; |
| B25 |
Electronic attenuator 0 to 30 dB, Preamplifier 20 dB, 10MHz - 3.6 GHz for FSU, FSQ |
| B28 |
Trigger port for FSP,FSQ,FSU; for indication of trigger conditions |
| B33 |
Disabled USB ports excludes FS-K9 |
| B4 |
OCXO 10 MHz aging/year: 0.35*10E-7 for FSU, FSQ, FSMR |
| B5 |
Output for low phase noise 640MHz reference signal for FSU3, FSU8, FSQ3 und FSQ8 |
| B71 |
Analogue base band inputs 50 Ohm/1M Ohm input impedance information bandwidth 36 MHz |
| B72 |
Bandwidth extension for IQ-Demodulation and Vectorsignalanalysis 120MHz IQ bandwidth. |
| B88 |
RF hardware option 1 FSQ26 |
| B9 |
Tracking generator for FSU and FSQ, 100 kHz - 3.6 GHz |
| C3 |
Three years of depot calibration coverage based on the R&S recommended calibration interval - includes test data. The first calibration is included with product delivery with 2 additional depot calibration(s). |
| C5 |
Five years of calibration coverage based on the R&S recommended calibration interval - includes test data. The first calibration is included with product delivery with 4 additional depot calibration(s). |
| DCV-2 |
Documentation of calibration values |
| DCV-ZP |
Printout of DCV (additional, in combination with DCV-Option only) |
| DKD |
FSQ26 DKD (ISO17025) calibration incl. ISO 9000 calibration (order only with device) |
| EX-IQ-BOX |
Digital I/O adapter module for AFQ, AMU, FMU, FSG, FSQ, SMJ, SMU (AFQ-B18, AMU-B17, AMU-B18, FSQ-B17, |
| FS-B33 |
USB mass memory write protection, disables writing to USB memory sticks (ex factory only) |
| FS-K10 |
GSM/EDGE/EDGE Evolution Measurement Appl (for FSG/FSQ/FSU) |
| FS-K110 |
Analysis of TETRA II / TEDS signals (for FSQ, FSU with option FSU-B73) |
| FS-K15 |
VOR/ILS measurements for FSMR |
| FS-K30 |
Application firmware for noise figure and gain measurements for FSMR, FSP, FSQ, FSU |
| FS-K40 |
Application firmware for phase noise measurements for FSMR, FSP, FSQ, FSU |
| FS-K5 |
Application firmware GSM/EDGE tests for FSP, FSU, FSQ |
| FS-K5U |
Upgrade of FS-K5 to FS-K10, GSM/EDGE/EDGE Evolution Measurement Appl (for FSG, FSQ, FSU) |
| FS-K7 |
FM demodulator, allows measurement of FM specific parameters (for FMU, FSP, FSU) |
| FS-K72 |
Application firmware 3GPP-FDD BTS transmitter test for FSMR, FSP, FSU, FSQ |
| FS-K73 |
Application firmware 3GPP-FDD UE transmitter test for FSMR, FSP, FSU, FSQ |
| FS-K73+ |
3GPP HSPA+ UE transmitter test, application firmware (for FSMR, FSP, FSQ, FSU, FSUP, |
| FS-K74 |
3GPP HSDPA base station test application firmware for FSMR, FSU, FSP, FSQ |
| FS-K74+ |
3GPP HSPA plus, base station test. Application firmware (for FSP, FSQ, FSU, FSG; |
| FS-K76 |
3GPP TD-SCDMA base station test; application firmware for FSMR, FSP, FSQ, FSU |
| FS-K77 |
3GPP TD-SCDMA mobile station test; application firmware for FSMR, FSP, FSQ, FSU |
| FS-K8 |
Application firmware for Bluetooth measurement on FSP, FSU and FSQ |
| FS-K82 |
CDMA2000/1xEV-DV base station test application firmware for FSMR, FSP, FSU, FSQ |
| FS-K83 |
CDMA2000/1xEV-DV mobile station application firmware for FSMR, FSP, FSQ, FSU |
| FS-K84 |
1xEV-DO base station test application firmware for FSMR, FSU, FSP, FSQ |
| FS-K85 |
1xEV-DO mobile station test application firmware for FSMR, FSP, FSQ, FSU |
| FS-K9 |
Measurements with NRP power sensors NRPZ11/Z21/Z22/Z23/Z24/Z51/Z55/Z91 requires NRP-Z3 or NRP-Z4 |
| FSP-B10 |
External generator control for FSP, FSU, FSG, FSQ, ESU, ESCI, ESPI and for retrofit of |
| FSP-B28 |
Trigger port for FSP,FSQ,FSU; for indication of trigger conditions |
| FSU-B12 |
Output attenuator for tracking generator for FSU, FSQ |
| FSU-B21 |
LO/ZF connections for external mixers (for FSQ26, FSQ40,FSU26, FSU43, FSU46, FSU50) |
| FSU-B24 |
Preamplifier 30dB, 100 kHz to 50GHz (for FSMR26/43/50, FSQ26/40, FSU26/43/46/50; |
| FSU-B25 |
Electronic attenuator 0 to 30 dB, Preamplifier 20 dB, 10MHz - 3.6 GHz for FSU, FSQ |
| FSU-B4 |
OCXO 10 MHz aging/year: 0.35*10E-7 for FSU, FSQ, FSMR |
| FSU-B5 |
Output for low phase noise 640MHz reference signal for FSU3, FSU8, FSQ3 und FSQ8 |
| FSU-B9 |
Tracking generator for FSU and FSQ, 100 kHz - 3.6 GHz |
| K100 |
EUTRA/LTE downlink, application firmware |
| K101 |
EUTRA/LTE uplink, application firmware |
| K102 |
EUTRA/LTE Downlink, MIMO. PC software for FSG and FSQ (FSQ-K100 required) |
| K104 |
Analysis of EUTRA/LTE TDD downlink signals (for FSG, FSQ) |
| K105 |
Analysis of EUTRA/LTE TDD uplink signals (for FSG, FSQ) |
| K3 |
Noise Figure Measurement Software |
| K30 |
Application firmware for noise figure and gain measurements for FSMR, FSP, FSQ, FSU |
| K4 |
PHASE NOISE |
| K40 |
Application firmware for phase noise measurements for FSMR, FSP, FSQ, FSU |
| K5 |
Application firmware GSM/EDGE tests for FSP, FSU, FSQ |
| K7 |
FM demodulator, allows measurement of FM specific parameters (for FMU, FSP, FSU) |
| K70 |
Vector signal analysis for FSQ; 28 MHz demodulator-BW FSK, MSK, PSK, |
| K72 |
Application firmware 3GPP-FDD BTS transmitter test for FSMR, FSP, FSU, FSQ |
| K73 |
Application firmware 3GPP-FDD UE transmitter test for FSMR, FSP, FSU, FSQ |
| K74 |
3GPP HSDPA base station test application firmware for FSMR, FSU, FSP, FSQ |
| K74+ |
3GPP HSPA plus, base station test |
| K76 |
3GPP TD-SCDMA base station test; application firmware for FSMR, FSP, FSQ, FSU |
| K77 |
3GPP TD-SCDMA mobile station test; application firmware for FSMR, FSP, FSQ, FSU |
| K8 |
Application firmware for Bluetooth measurement on FSP, FSU and FSQ |
| K82 |
CDMA2000/1xEV-DV base station test application firmware for FSMR, FSP, FSU, FSQ |
| K83 |
CDMA2000/1xEV-DV mobile station application firmware for FSMR, FSP, FSQ, FSU |
| K84 |
1xEV-DO base station test application firmware for FSMR, FSU, FSP, FSQ |
| K85 |
1xEV-DO mobile station test application firmware for FSMR, FSP, FSQ, FSU |
| K9 |
Measurements with NRP power sensors NRP-Z11/Z21/Z22/Z23/Z24/Z51/Z55/Z91 requires NRP-Z3 or NRP-Z4 |
| K90 |
Application firmware WLAN 802.11A TX tests (EMV, flatness, mask) for FSQ |
| K90U |
Upgrade from FSQ-K90 to FSQ-K91, 802.11A,B,G,J TX tests requires 512 MB memory |
| K91 |
Application firmware WLAN 802.11A,B,G,J TX tests requires 512 MB memory |
| K91AC |
Upgrade of FSQ-K91 to 802.11ac |
| K91N |
Upgrade of FSQ-K91 to 802.11n |
| K92 |
Application firmware WIMAX (802.16-2004) TX measurements |
| K92U |
Upgrade of FSQ-K92 to FSQ-K93 |
| K93 |
Application firmware for WIMAX IEEE 802.16e, WIBRO |
| K94 |
Application firmware for WIMAX IEEE 802.16e-2005 MIMO |
| K96 |
Generic OFDM measurement demodulator. Selectable pilot and data carriers and modulation type |
| Q3-DKD |
ISO 9000 Calibration / data |
| R3 |
Three years of depot repair coverage, including recalibration and test data if necessary to complete the repair. First year of repair coverage is provided by the 12-month new product warranty. |
| R5 |
Five years of depot repair coverage, including re-calibration if necessary to complete the repair. First year of repair coverage is provided by the 12-month new product warranty. |
| U2 |
WINDOWS XP UPGRADE |
| U3 |
CPU board upgrade and 1.5GB memory extension for FSQ without flash drive FSQ-B18 |
| Z110 |
External Harmonic Mixer 90 - 110 GHz |
| Z2 |
Compact Keyboard with Trackball |
| Z4 |
DC Block 10 KHz - 18 GHz N Connector 50 Ohm, 50 VDC |
| Z5 |
2.4 mm Test Port Adapter |
| Z60 |
External Harmonic Mixer 40 - 60 GHz |
| Z75 |
External Harmonic Mixer 50 - 75 GHz |
| Z90 |
External Harmonic Mixer 60 - 90 GHz |
| ZZA-411 |
19" adapter, 4 HU, 1/1 for BW2000 cabinets |
