HP / Keysight / Agilent N9020A - Spectrum Analyzers

Standards evolve, product cycles get shorter, and each project demands tradeoffs and decisions about specs and capabilities, about throughput and yield. A highly flexible signal analyzer helps you make solid choices and keep things moving —quickly. The Agilent MXA is the accelerator as you develop new wireless devices and deliver them to manufacturing and the marketplace. It has the versatility to easily adapt to your evolving test requirements, today and tomorrow. Address multiple formats, generations and devices with the MXA —and accelerate in wireless.

The MXA signal analyzer is a member of the X-Series, which is an evolutionary approach to signal analysis that spans instrumentation, measurements and software. It gives you the flexibility to satisfy your business and technical requirements across multiple products and programs - now and in the future.

_{Windows and MS Windows are U.S. registered trademarks of Microsoft Corporation}

Functionality

• 20 Hz to 3.6, 8.4, 13.6, or 26.5 GHz; internal preamplifier options up to 26.5 GHz
• 25 MHz (standard) or 40 MHz (optional) analysis bandwidth
• Basic EMI precompliance measurement capability available, including CISPR 16-1-1 bandwidths, detectors, amplitude correction factor, band preset, tune & listen at marker, and limit lines
• View configuration choices for MXA Instrument Hardware

Performance

• ±0.23 dB absolute amplitude accuracy
• +20 dBm third order intercept (TOI)
• -166 dBm displayed average noise level (DANL) with preamplifier
• -78 dB W-CDMA ACLR dynamic range (with noise correction on)

Measurement Applications & Software

• MXA supports over 25 measurement applications, covering cellular communication, wireless connectivity, digital video and general purpose. View full list of measurement applications
• Advanced analysis of more than 70 signal formats, software runs inside the MXA. 89600B VSA software
• MATLAB^® data analysis software for general purpose data analysis, visualization, and measurement automation. MATLAB software for the X-Series
• Agilent''s PowerSuite one-button power measurements included as standard

Automation & Communication Interface

• LXI class C compliant, SCPI and IVI-COM
• USB 2.0, 1000Base-T LAN, GPIB
• Programming remote language compatibility with PSA, 8566/68, and 856x
• Common X-Series user interface / Open Windows^® XP operating system
